Revit Electrical



Illuminate Your Career with Revit Electrical

Specialize in the electrical aspects of building design with our Revit Electrical course. This training provides you with the knowledge to design and document electrical systems with precision. Whether it’s power distribution, lighting, or fire alarm systems, Revit Electrical equips you with the tools to create comprehensive BIM models that enhance project efficiency. Stand out in the competitive field of electrical engineering by mastering the software that’s transforming the AEC industry.

What You Will Learn from Revit Structure

• Introduction to BIM

Gain a solid understanding of Building Information Modeling (BIM) principles.

• Building Life Cycle Management

Understand the full lifecycle of a building, from design to demolition.

• Construction Scheduling:

Learn to prepare and format schedules for construction elements efficiently

• Interdisciplinary Coordination

Coordinate effectively with other disciplines to ensure project alignment.

• Clash Detection and Resolution:

Use Navisworks to develop clash-free models.

• Proficiency in Revit

Develop the ability to work effectively in Revit, creating coordinated models and detailed documents.

• Architectural Elements Mastery

Professionally design and manage architectural elements within Revit

• Common Data Environment (CDE)

Work within a Common Data Environment for seamless collaboration.

• Adherence to Senior Engineers' Guidance

Follow instructions from senior engineers to develop accurate Revit documentation.

• Realistic 3D Visualization

Create realistic 3D images by applying materials to your models.

Who is Eligible?

1. Fresh Diploma or BE Civil Graduates Interested in BIM and Design Office Roles
Recent graduates with a Diploma or a Bachelor’s degree in Civil Engineering who are eager to pursue careers in Building Information Modeling (BIM) and design office environments.

2. Civil Contractors or Engineers Executing Projects
Professionals currently working as civil contractors or engineers who are directly involved in the execution of construction projects and are looking to enhance their skills in BIM.

3. Experienced Professionals Ready to Transition to BIM Design Offices
Experienced professionals who are currently working in the construction or engineering fields and are interested in transitioning to a BIM-focused design office role.

4. Managers Interested in Understanding BIM
Project managers or other managerial-level professionals who are keen to gain a deeper understanding of BIM processes to improve project coordination and efficiency.

Detailed Syllabus

 Introduction to BIM
 Create a Project file from template
 Underastand user interface
 How bim work
 Understand different disciplines of Building
 Building life cycle
 Future of bim
 Revit file extensions
 Type and instance properties
 Short cuts in Revit

 Creating Floor plan,section and Elevations
 Duplication of view
 View Crop properties
 View control bar options
 View model using filter,visual graphics
 View instance properties
 Scope box properties
 View range
 View cube and Navigation bar options
 Callout and reference views
 3D Visual Styles

Create Duplicate Views
 Duplicate view as dependent
 Create Match line
 Add Reference to views
 Create Call out view
 Place in Sheets
 View Crop Properties
 Visual graphics
 Filters in view
 View range
 Plan region view
 Scope box properties
 Modifying view controls
 Discipline
 Under Lay of View
 Selection of Objects
 Hide and Unhide Elements

 Create Mechanical/Electrical file From template
 Link Arch Model
 Use different options for linking
 Copy monitor levels and grids
 Room bounding Option
 Understand Phase in Linking
 Tag Room Names
 Create Master Elevation and Plan Views
 Understand Co-ordination Review
 Link Unload/Reload
 Reload From Option

 Place Lights
 Place Lights with work Plane
 Change Different type of Lights
 Place Lights on Wall
 Create Ceiling Plan
 Difference between Ceiling plan and Floor plan
 Change Workplace of light
 Type properties of Light
 Instance properties of light
 Adjusting Tiles in Ceiling Plan
 Ines File in Lights
 Visibility Graphics of Light
 Group of Lights

 Place Electrical Device,switches and Electrical Equipment
 Place Cable tray,conduits
 Cable tray offset
 Cable tray type and Instance properties
 Cable tray configuration for Intersection
 Place conduit
 Conduit configuration
 Placing conduits inside cable tray
 Conduit and cable tray schedule

 Voltage and Distribution System Configuration
 Configure Families
 Create Lighting Circuit
 Add Power to Circuit
 Add Switches to Circuit
 Create Data,Communication,Fire Alarm Schedule
 Create Panel Schedule
 Edit Panel Schedule
 Check System Browser
 Add Wires to Circuit and Change
 Load Calculations
 Wire Settings
 Panel Schedule Template

 Tag by Category, Room tag and tag all
 Spot elevation/Spot Co-ordinate/Spot Slope
 Place text,justification,find and replace
 Leaders
 Dimension Linear/Radial/Diameter Elements
 Detail line /Regions
 Revision Cloud
 Key notes
 Title block edit
 Symbols
 Custom Title Book

 Create Worksets
 Create Central File
 Backup of Central File
 History of Central File
 Copy monitor Elements
 Co-ordination Review
 Worksets assign to Elements
 Clash Detection With in File
 Clash Detection With, Linked Elements
 Save Views with Worksets
 Worksets optionsith Linked Elements
 Save Views with workset

 Insert AutoCAD File
 Insert Revit File
 Understand Options of insert Revit
 Add images in project
 Manage Link File
 Manage Decal
 Insert views from other Revit files
 Insert 2D Elements from other files

 Topics
 Transfer properties from other files
 Object Styles
 Line Style/Fill pattern Create and Manage
 Project Information and Parameters
 Shared Parameters
 Project Location and Properties
 Element ID and Search
 Warnings in Model
 Macros in Revit
 Units, Snap in Model
 Project Parameters
 Material

 Room and Room Tag
 Creating Spaces
 Modifying Spaces
 Area and Volume Calculation
 Creating Zone
 Systems Browser and Zone
 Colour Scheme

 Add Fields in Schedule
 Use Sorting and Grouping in schedule
 Use Filter in Schedule
 Format Field in schedule
 Calculate Totals
 Formatting header and schedule lines/Fonts
 Phases in Schedule
 Schedule from Linked file
 Create calculated Value in Schedule
 Count and Sum of Fields

 Add Filed in Schedule
 Use Sorting and Grouping in schedule
 Use Filter in Schedule
 Format Field in schedule
 Calculate Totals
 Format header and schedule lines/Fonts
 Phases in Schedule
 Schedule from Linked file

 Loading of Families
 View Families in Project browser
 Types of Families
 Editing annotation family
 Create model in place family
 Elements of Family
 Family Category and Parameters
 List of websites providing Revit families
 Modelling in Family using Extrusion Blend, Resolve, Sweep
 Void in Family
 Visibility in Family
 Reference plane and assigning Parameters
 Create Symbolic lines Family



 Align grid
 Guide grid
 Consistence in line styles
 Using view templates
 Printing options
 Saving print sets
 Margins in Sheets
 Title on Sheet Value
 View List
 Sheet List

 View elements according to Host
 View elements according to link
 View elements according to custom
 Worksets for viewing model
 Using Filters List in View
 Using View Template and Assign
 Managing Starting View
 Project Browser Management
 Title on Sheet View
 Managing View Title Family

 Single Floor Project With 7 Rooms of total 200 Square meter
 Project Should have all Family name and View names
 Warning Should be minimum
 All the Sheet view should be places in Sheet
 Create Schedule for Wall , Door and Window with Count
 Project Information to be filled
 All the Floor plan should be dimensioned and tagging
 Develop Four Elevations and Dimension them
 Develop two Sections of the Building
 Show 3D View for all the Rooms
 Minimum 10 Sheets in the project
