Revit Mechanical

Revolutionize Building Systems with Revit Mechanical

Take control of mechanical systems design with our Revit Mechanical course. Learn to create efficient HVAC, plumbing, and piping systems that integrate seamlessly into your BIM models. Our training ensures you understand the critical aspects of mechanical design while leveraging Revit’s capabilities to produce detailed and coordinated models. Equip yourself with the skills that are in high demand in the construction industry, and become a sought-after professional in mechanical design

What You Will Learn from Revit Mechanical

• Introduction to BIM

Gain a solid understanding of Building Information Modeling (BIM) principles.

• Building Life Cycle Management

Understand the full lifecycle of a building, from design to demolition.

• Construction Scheduling:

Learn to prepare and format schedules for construction elements efficiently

• Interdisciplinary Coordination

Coordinate effectively with other disciplines to ensure project alignment.

• Clash Detection and Resolution:

Use Navisworks to develop clash-free models.

• Proficiency in Revit

Develop the ability to work effectively in Revit, creating coordinated models and detailed documents.

• Architectural Elements Mastery

Professionally design and manage architectural elements within Revit

• Common Data Environment (CDE)

Work within a Common Data Environment for seamless collaboration.

• Adherence to Senior Engineers' Guidance

Follow instructions from senior engineers to develop accurate Revit documentation.

• Realistic 3D Visualization

Create realistic 3D images by applying materials to your models.

Who is Eligible?

1. Fresh Diploma or BE Civil Graduates Interested in BIM and Design Office Roles
Recent graduates with a Diploma or a Bachelor’s degree in Civil Engineering who are eager to pursue careers in Building Information Modeling (BIM) and design office environments.

2. Civil Contractors or Engineers Executing Projects
Professionals currently working as civil contractors or engineers who are directly involved in the execution of construction projects and are looking to enhance their skills in BIM.

3. Experienced Professionals Ready to Transition to BIM Design Offices
Experienced professionals who are currently working in the construction or engineering fields and are interested in transitioning to a BIM-focused design office role.

4. Managers Interested in Understanding BIM
Project managers or other managerial-level professionals who are keen to gain a deeper understanding of BIM processes to improve project coordination and efficiency.

Detailed Syllabus

 Introduction to BIM
 Create a Project file from template
 Underastand user interface
 How bim work
 Understand different disciplines of Building
 Building life cycle
 Future of bim
 Revit file extensions
 Type and instance properties
 Short cuts in Revit

 Creating Floor plan,section and Elevations
 Duplication of view
 View Crop properties
 View control bar options
 View model using filter,visual graphics
 View instance properties
 Scope box properties
 View range
 View cube and Navigation bar options
 Callout and reference views
 3D Visual Styles

Create Duplicate Views
 Duplicate view as dependent
 Create Match line
 Add Reference to views
 Create Call out view
 Place in Sheets
 View Crop Properties
 Visual graphics
 Filters in view
 View range
 Plan region view
 Scope box properties
 Modifying view controls
 Discipline
 Under Lay of View
 Selection of Objects
 Hide and Unhide Elements

 Create Mechanical/Electrical file From template
 Link Arch Model
 Use different options for linking
 Copy monitor levels and grids
 Room bounding Option
 Understand Phase in Linking
 Tag Room Names
 Create Master Elevation and Plan Views
 Understand Co-ordination Review
 Link Unload/Reload
 Reload From Option

 Place Ducts
 Place Mechanical Equipment
 Change Different type of Ducts
 Add Air terminals
 Add Flex Ducts
 Connect duct with equipment
 Change the equipment size as mentioned
 Width,Height and Offset of Duct
 Justification in ducts
 Bottom of duct and offset
 Draw ducts in section view
 Check the disconnections in ducting
 Use Different type of Ducts

 Setup the routing preference of duct in edit type
 Add air terminals(supply and return)
 Adding and Modifying Fittings
 Place duct accessories
 Work with duct fitting control
 Create Legend of Duct Properties
 Mechanical Settings
 Filter for Mechanical System
 Schedule for Mechanical System
 LOD 400 Connections
 Different Duct Fittings
 Change Duct Offset and Routing

 Place Pipes
 Place Plumbing Equipment
 Place Pipe Fittings and Pipe Accessories
 Connect with Equipment
 Pipe Instance properties
 Pipe Type Properties
 Placing Slope in Pipes
 Changing Diameter and offset in Pipes
 Tag by category,Room tag and tag all
 Spot elevation/Spot Co-ordinate/Spot Slope
 Place text,justification,find and replace
 Leaders

 Create Fire Pipe
 Add Sprinklers
 Connect Sprinklers with Pipe
 Modifying Sprinklers type
 Sprinkler Type Properties
 Sprinkler instance Properties
 Change Sprinkler Height
 Give sprinkler offset
 Duplicate Fire System
 Check Fire Layout System Browser
 Checking Systems for Disconnection
 Adding Connectors and modifying connectors

 Paint Element
 Rotate, Move& Scale Elements
 Polar and Rectangular Array Elements
 Align,Split,Joint Elements
 Mange Selection of elements
 Viewing Elements in Linked Files
 Selection set of Elements
 Select and Un-Select Elements in Link
 Use of Create similar
 Clip board Options Paste from clipboard, align to selected levels, align to selected views

 Tag by Category, Room tag and tag all
 Spot elevation/Spot Co-ordinate/Spot Slope
 Place text,justification,find and replace
 Leaders
 Dimension Linear/Radial/Diameter Elements
 Detail line /Regions
 Revision Cloud
 Key notes
 Title block edit
 Symbols
 Custom Title Book

 Create Worksets
 Create Central File
 Backup of Central File
 History of Central File
 Copy monitor Elements
 Co-ordination Review
 Worksets assign to Elements
 Clash Detection With in File
 Clash Detection With, Linked Elements
 Save Views with Worksets
 Worksets optionsith Linked Elements
 Save Views with workset

 Insert AutoCAD File
 Insert Revit File
 Understand Options of insert Revit
 Add images in project
 Manage Link File
 Manage Decal
 Insert views from other Revit files
 Insert 2D Elements from other files

 Topics
 Transfer properties from other files
 Object Styles
 Line Style/Fill pattern Create and Manage
 Project Information and Parameters
 Shared Parameters
 Project Location and Properties
 Element ID and Search
 Warnings in Model
 Macros in Revit
 Units, Snap in Model
 Project Parameters
 Material

Duct Systems and Mechanical Settings

 System Browser
 Graphic Overrides
 Checking Systems
 System Inspector
 Duct Sizing

Create Schedules

 Add Filed in Schedule
 Use Sorting and Grouping in schedule
 Use Filter in Schedule
 Format Field in schedule
 Calculate Totals
 Format header and schedule lines/Fonts
 Phases in Schedule
 Schedule from Linked file

 Loading of Families
 View Families in Project browser
 Types of Families
 Editing annotation family
 Create model in place family
 Elements of Family
 Family Category and Parameters
 List of websites providing Revit families
 Modelling in Family using Extrusion Blend, Resolve, Sweep
 Void in Family
 Visibility in Family
 Reference plane and assigning Parameters
 Create Symbolic lines Family

Presentation of Documents and Printing

 Align grid
 Guide grid
 Consistence in line styles
 Using view templates
 Printing options
 Saving print sets
 Margins in Sheets
 Title on Sheet Value
 View List
 Sheet List

 Align grid
 Guide grid
 Consistence in line styles
 Using view templates
 Printing options
 Saving print sets
 Margins in Sheets
 Title on Sheet Value
 View List
 Sheet List

 View elements according to Host
 View elements according to link
 View elements according to custom
 Worksets for viewing model
 Using Filters List in View
 Using View Template and Assign
 Managing Starting View
 Project Browser Management
 Title on Sheet View
 Managing View Title Family

 Single Floor Project With 7 Rooms of total 200 Square meter
 Project Should have all Family name and View names
 Warning Should be minimum
 All the Sheet view should be places in Sheet
 Create Schedule for Wall , Door and Window with Count
 Project Information to be filled
 All the Floor plan should be dimensioned and tagging
 Develop Four Elevations and Dimension them
 Develop two Sections of the Building
 Show 3D View for all the Rooms
 Minimum 10 Sheets in the project
